Motherboard MSI Z390 Gaming Plus
Las placas madre de MSI cuentan con la última solución para jugadores entusiastas y jugadores avanzados. La mejora de la memoria y la CPU, el almacenamiento rápido y la velocidad de transferencia USB están listos para estar en el campo de batalla.
Los materiales de alta calidad y las optimizaciones inteligentes de los ventiladores contribuyen a enfriar todos los componentes esenciales, lo que es clave para garantizar que su sistema funcione de manera estable y que ofrezca el mejor rendimiento en todo momento.
Datasheet
https://asset.msi.com/pdf/main/global/presale_v2/MPG-Z390-GAMING-PLUS? Marca: Msi Part Number: Z390 Cpu: Supports Intel® Core™ 9000 Series family/ 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket Chipset: Intel® Z390 Chipset Memoria: 4 x DDR4 memory slots, support up to 128GB Supports DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile (XMP) Gráficos: 1 x HDMI™ port, supports a maximum resolution of 4096x2160@24Hz 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz Audio: Realtek® ALC892 Codec 7.1-Channel High Definition Audio Lan: 1 x Intel® I219-V Gigabit LAN controller Conectores: 1 x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 6x SATA 6Gb/s connectors 3x M.2 slots (2 M-Key slots,1 E-Key slot) 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin Water Pump connector 5x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x TPM module connector 2x 4-pin RGB LED connectors 1x Serial Port connector 1x Clear CMOS jumper Panel Trasero E/s: PS/2 Combo Port LAN HD Audio Connectors USB 2.0 DVI-D HDMI USB 3.1 Gen2 Type-A + C USB 3.1 Gen1 Caract. Especiales: 12 in. x 9.6 in. (30.5 cm x 24.4 cm) ATX Form Factor Socket: 1151 Almacenamiento: Intel® Z390 Chipset 6 x SATA 6Gb/s ports1 2 x M.2 slot (Key M)1 M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices Intel® Optane™ Memory Ready2 Raid: Intel® Z390 Chipset Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 for M.2 PCIe storage devices Slots: 2 x PCIe 3.0 x16 slots 4 x PCIe 3.0 x1 slots 1 x M.2 slot with E key for Integrated Intel® Wireless-AC(CNVi) module only Usb: Intel® Z390 Chipset 2 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1x Type-A port and 1x Type-C port) on the back panel 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 3.1 connectors) 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)1
